Maximum Stroke (mm)
Up to 800, Up to 1200, Up to 1500, Up to 800 (Standard), Longer (Special), Up to 500 (Standard)
Maximum Stroke (inch)
Up to 31.5, Up to 47.2, Up to 59.1, Up to 31.5 (Standard), Longer (Special), Up to 19.7 (Standard)
Extend Stroke Thrust (N)
754 (at 6 bar), 1178 (at 6 bar), 1869 (at 6 bar), 3014 (at 6 bar), 4710 (at 6 bar), 7359 (at 6 bar), 10598 (at 6 bar), 15260 (at 6 bar), 18840 (at 6 bar), 29438 (at 6 bar), 1508 (at 6 bar), 2356 (at 6 bar), 3738 (at 6 bar), 6028 (at 6 bar), 9420 (at 6 bar
Extend Stroke Thrust (lbs)
-
Retract Stroke Thrust (N)
633 (at 6 bar), 989 (at 6 bar), 1681 (at 6 bar), 2720 (at 6 bar), 4286 (at 6 bar), 6782 (at 6 bar), 9844 (at 6 bar), 14307 (at 6 bar), 17663 (at 6 bar), 27742 (at 6 bar), 1266 (at 6 bar), 1978 (at 6 bar), 3362 (at 6 bar), 5440 (at 6 bar), 8572 (at 6 bar),
Retract Stroke Thrust (lbs)
-
Cushioning Type
Adjustable
Port Size
PT 1/4, PT 3/8, PT 1/2, PT 3/4, PT 1
Maximum Working Pressure (bar)
9
Maximum Working Pressure (psi)
130
Operating Temperature (C)
5 to 60
Operating Temperature (F)
41 to 140
Position Sensing
All, n/a
Piston Rod Material
Chrome Plated Steel
End Cap Material
Aluminum, Casting
Corrosion-Resistant Option
No
Liên hệ trực tiếp đến chúng tôi theo Hotline/ zalo 0937 664 929 hoặc email phuc.dao@phucthinh-tech.com
Xy lanh khí Parker GDCN125-250
Xy lanh khí Parker GDCN125-250 được thiết kế gọn nhẹ. Xy lanh khí Parker GDCN125-250 ứng dụng cho nhiều lĩnh vực
Vui lòng liên hệ để được báo giá tốt nhất cho Xy lanh khí Parker GDCN125-250
Email : phuc.dao@phucthinh-tech.com
M/ Zalo: 0937 664 929
The GDC series, the tie rod cylinder, offers a wide range of bore sizes, multiple mounting configurations and auto switch capability as a standard.
• Improved energy absorption capacity
• Cylinder with high tech appearance
• Aluminum and Steel tube
• Tube size (mm): 40~250
• Improved cushion capacity
• Compact and lightweight design
• Increase kinetic energy absorption
