Được sản xuất từ vật liệu chất lượng cao, chống ăn mòn, có sẵn nhiều lựa chọn về kích cỡ, hành trình và đường kính, các xi lanh khí nén của Parker, các phụ kiện và các bộ phụ tùng (KIT) có độ tin cậy và hiệu suất cao. Dải sản phẩm đầy đủ bao gồm các xi lanh khí nén tiêu chuẩn, xi lanh nhôm, xi lanh dẫn hướng, xi lanh ISO, xi lanh có biên dạng siêu nhỏ cho tới các xi lanh thép không gỉ.
Liên hệ trực tiếp đến chúng tôi theo Hotline/ zalo 0937 664 929 hoặc email phuc.dao@phucthinh-tech.com
- The P5E series guided cylinder is designed to be a lighter weight solution for standard duty linear motion applications. Two parallel precision ground case hardened, or stainless steel, support shafts are guided by four linear bushings and incorporated into the body assembly. The bearings are prelubricated to provide millions of trouble-free cycles. Composite bushings are standard with all three shaft styles and available with oversized shafting. Optional linear ball bearings are available with stainless steel shafting only. The P5E series features a one-piece cast aluminum body with tapped and counterbored mounting holes. Standard dowel pin holes provide precision mounting for the body and tool plate. The P1D cylinder utilizes an alignment coupler which prevents the piston rod from deflecting under high loads or long strokes. Standard piston wear bands allow the piston rod assembly to "float" in the bore thereby eliminating metal-to-metal contact. The result is dramatically greater cylinder seal life especially when the support shafts deflect under load. This ensures very long cylinder life with reduced maintenance and downtime.
• Bore sizes: 32, 40, 50, 63, 80, and 100 mm
• Stroke length: available in any practical length to 1350 mm (varies by series and guide rod size, longer available, consult factory)
• Operating characteristics: double acting
• Maximum operating pressure: 1 MPa (145 psi or 10 bar)
• Operating temperature range: 14°F to 165°F or -10°C to 74°C
• Support rod sizes: 12, 16, 20, 25, and 30 mm
• Energy absorption: bumpers and cushions
• Stroke adjustment: adjustable stop collars
• Flow controls: Presto-lok and NPT
• Cylinder mounting: ISO 6431 and DIN 24335
• Switches and Sensors: standard magnetic piston, optional reed switches or solid state and proximity sensors. Sold separately.
• Filtration requirement: 40 micron filtered, dry air
• Contaminant-tolerant shaft seals
• Rod lock option available
