| Port Type: | BSPP “G” |
| Operating Temperature (F): | 0 - 180 |
| Materials : Diaphragm: | Standard - Urethane (Nitrile static seals) |
| Port 1 Size (inch): | 1/4 |
| Port 2 Size (inch): | 1/4 |
| Port 3 Size (inch): | 3/8 |
| Product Type: | Rapid Exhaust | Shuttle Valve |
| Mounting Type: | Inline |
| Port Connection: | Female to Female |
| Port Size: | 1/8" | 1/4" | 3/8" | 1/2" | 3/4" |
| Port Type: | NPT | BSPP |
| Flow Coefficient: | 2.7 to 10.0 Cv |
| Flow Rate: | 150 to 550 SCFM |
| Operating Pressure: | 3 to 200, 0 to 13.8 bar |
| Operating Temperature: | -18 to 260 °C, 0 to 500 °F |
| Media: | Air |
| Lubricant: | None |
| Body Material: | Die Cast Aluminum |
| Seal Material: | Urethane, Nitrile, Flourcarbon or PTFE |
