NNR-2-026
NNR-2-026
| Standard Pack Qty (ft): | 500 |
| Order Size: | 1/8 |
| Specifications Met: | n/a |
| Application: | Fluid Transfer, Lubrication, Marine, Pneumatics |
| Tube Inside Diameter: | 0.073 inch, 1.9 mm |
| Tube Outside Diameter: | 1/8 inch, 3.2 mm |
| Color: | Natural |
| Maximum Operating Pressure: | 625 psi, 43.1 bar |
| Minimum Burst Pressure: | 2500 psi, 172.4 bar |
| Maximum Operating Temperature: | 200 °F, 93 °C |
| Minimum Operating Temperature: | -60 °F, -51 °C |
| Minimum Bend Radius: | 0.38 inch, 9.7 mm |
| Compatible Fitting: | Compress-Align®, Compression, Fast & Tite®, Flow Controls, Hi-Duty, Metric Compression, TrueSeal™, Prestolok® |
| Media: | Air, Hydraulic Fluids, Lubricants, Fuels (Oil), Water |
| Cover Color: | n/a |
| Weight: | 0.004 lb/ft, 0.006 kg/m |
| Tube Material: | Polyamide (PA) |
| Cover Material: | n/a |
| Length per Package: | 34.8 m, 500 ft |
| Size: | -2 |
NNR-2-026
