DOWNLOAD CATALOGUE PARKER Regulator
Specifications Flow Capacity* 1/4 112 SCFM (53 dm3/s) 3/8 148 SCFM (70 dm3/s) 1/2 185 SCFM (87 dm3/s) Adjusting Range Pressure 0 to 60 PSIG (0 to 4.1 bar) 0 to 125 PSIG (0 to 8.6 bar) 0 to 250 PSIG (0 to 17.2 bar) Gauge Port (2 ea.) NPT / BSPT-Rc 1/4 Operating Temperature 32° to 150°F (0° to 65.5°C) Maximum Supply Pressure 300 PSIG (21 bar) Port Size NPT / BSPP-G 1/4, 3/8, 1/2 Weight lb. (kg) 2.5 (1.34) * Inlet pressure 100 PSIG (6.9 bar). Secondary pressure 90 PSIG (6.2 bar). Materials of Construction Body Zinc Bonnet PBT Diaphragm Nitrile / Zinc Panel Nut Acetal Seals Nitrile Springs Steel Valve Assembly Brass / Nitrile / Acetal
Liên hệ trực tiếp đến chúng tôi theo Hotline/ zalo 0937 664 929 hoặc email phuc.dao@phucthinh-tech.com
Specifications Flow Capacity* 1/4 112 SCFM (53 dm3/s) 3/8 148 SCFM (70 dm3/s) 1/2 185 SCFM (87 dm3/s) Adjusting Range Pressure 0 to 60 PSIG (0 to 4.1 bar) 0 to 125 PSIG (0 to 8.6 bar) 0 to 250 PSIG (0 to 17.2 bar) Gauge Port (2 ea.) NPT / BSPT-Rc 1/4 Operating Temperature 32° to 150°F (0° to 65.5°C) Maximum Supply Pressure 300 PSIG (21 bar) Port Size NPT / BSPP-G 1/4, 3/8, 1/2 Weight lb. (kg) 2.5 (1.34) * Inlet pressure 100 PSIG (6.9 bar). Secondary pressure 90 PSIG (6.2 bar). Materials of Construction Body Zinc Bonnet PBT Diaphragm Nitrile / Zinc Panel Nut Acetal Seals Nitrile Springs Steel Valve Assembly Brass / Nitrile / Acetal
