| Product Series: | General Purpose Solenoid Valves |
| Voltage (V): | 24VDC |
| Valve Type: | 2-Way |
| Function: | Normally Open (NO) |
| Port Size: | 3/4 inch |
| Input Voltage: | 24.0 VDC |
| Body Material: | Brass |
| Seal Material: | PUR |
| Orifice 1 Size: | 15 mm |
| Flow Coefficient 1: | n/a, 53.3 L/min |
| Power (Watts): | 9 |
| Power Consumption: | 9 W |
| Coil Type: | Coil for DIN plug connection, 32 mm |
| Maximum Pressure Differential: | 40 bar |
| Minimum Pressure Differential: | 1.5 bar |
| Orifice 1 Size (mm): | 15 |
| Number of Ports: | 2 |
| Actuation Type: | Pilot Operated |
| Coil Type: | Coil for DIN plug connection, 32 mm |
| Media: | Air |
| Port Type: | BSP |
| Orifice 2 Size: | n/a |
| Flow Coefficient 2: | n/a |
| Minimum Fluid Temperature: | n/a |
| Maximum Fluid Temperature: | n/a |
| Coil Specifications Met: | IP65 |
| Flow Factor 1 (l/min): | 53.3 |
| Seal Material: | PUR |
