221G2523-852025-483824T1

221G2523-852025-483824T1

221G2523-852025-483824T1


Hãy trở thành người đầu tiên đánh giá sản phẩm này ( 0)
221G2523-852025-483824T1 Seal Material:FKM Port Size:1/2" G Electrical Connection:Screw terminals Function:Normally Closed Specifications Met:DIN-EN-ISO 23553-1 (2009-10) approved for oil burners Flow Coefficient 1:50 l/min Power Supply Voltage:230V 50Hz - 240V 60Hz Coil Specifications Met:CE - EAC - Housing 8760 Minimum Fluid Temperature:0 °C ATEX Specifications Met:- [...]

Liên hệ

  • Mã sản phẩm:
  • 221G2523-852025-483824T1
  • Đơn vị tính:
  • Cái
  • Tình trạng:

221G2523-852025-483824T1

  • Seal Material:FKM
  • Port Size:1/2" G
  • Electrical Connection:Screw terminals
  • Function:Normally Closed
  • Specifications Met:DIN-EN-ISO 23553-1 (2009-10) approved for oil burners
  • Flow Coefficient 1:50 l/min
  • Power Supply Voltage:230V 50Hz - 240V 60Hz
  • Coil Specifications Met:CE - EAC - Housing 8760
  • Minimum Fluid Temperature:0 °C
  • ATEX Specifications Met:-
  • Maximum Operating Pressure:5 bar
  • Actuation Type:Magnalift
  • Valve Type:2/2-Way
  • Port Type:Pipe Mounting
  • Media:Oils
  • Seat Material:Brass
  • Orifice Size:15 mm
  • Flow Coefficient 2:3 m3/hour
  • Minimum Operating Pressure:0 bar
  • Maximum Fluid Temperature:140 °C
  • Coil Power Consumption:19 W
  • Coil Temperature Range:-40 to 50 °C
Liên hệ trực tiếp đến chúng tôi theo Hotline/ zalo 0937 664 929  hoặc email phuc.dao@phucthinh-tech.com

221G2523-852025-483824T1

  • Seal Material:FKM
  • Port Size:1/2" G
  • Electrical Connection:Screw terminals
  • Function:Normally Closed
  • Specifications Met:DIN-EN-ISO 23553-1 (2009-10) approved for oil burners
  • Flow Coefficient 1:50 l/min
  • Power Supply Voltage:230V 50Hz - 240V 60Hz
  • Coil Specifications Met:CE - EAC - Housing 8760
  • Minimum Fluid Temperature:0 °C
  • ATEX Specifications Met:-
  • Maximum Operating Pressure:5 bar
  • Actuation Type:Magnalift
  • Valve Type:2/2-Way
  • Port Type:Pipe Mounting
  • Media:Oils
  • Seat Material:Brass
  • Orifice Size:15 mm
  • Flow Coefficient 2:3 m3/hour
  • Minimum Operating Pressure:0 bar
  • Maximum Fluid Temperature:140 °C
  • Coil Power Consumption:19 W
  • Coil Temperature Range:-40 to 50 °C
Tags: 221G2523-852025-483824T1, 221G2523
